Lawn Star LSBH 2625 P Petrol Blower IPL
This IPL page has been prepared from the Lawn Star 2026 spare parts manual. Use the diagram reference numbers together with the parts table below.
Spare parts list
| Ref | Description | Part Number | Cutsmart SKU | Qty |
|---|---|---|---|---|
| 1 | HEX SCREW M4X16 | 4 | ||
| 2 | PULL START EASY START | Refer to 88 Resolves to: VA-262-88 | VA-262-88-Online | 1 |
| 3 | STARTER BOWL | Refer to 88 Resolves to: VA-262-88 | VA-262-88-Online | 1 |
| 4 | CRANKCASE REAR | Refer to 89 Resolves to: VA-262-89 | VA-262-89-Online | 1 |
| 5 | CRANKCASE SEAL GASKET | Refer to 89/90 Resolves to: VA-262-89, VA-262-90 | VA-262-89-Online VA-262-90-Online | 1 |
| 6 | OIL SEAL TC12X22X7 | Refer to 89 Resolves to: VA-262-89 | VA-262-89-Online | 2 |
| 7 | BEARING 6001 | Refer to 89 Resolves to: VA-262-89 | VA-262-89-Online | 2 |
| 8 | CRANKSHAFT CONNECTING ROD SET | Refer to 89 Resolves to: VA-262-89 | VA-262-89-Online | 1 |
| 9 | WOODRUFF KEY13X3X3.7 | Refer to 89 Resolves to: VA-262-89 | VA-262-89-Online | 1 |
| 10 | CYLINDRICAL PIN B4X10 | Refer to 89 Resolves to: VA-262-89 | VA-262-89-Online | 2 |
| 11 | FRONT HALF CRANKCASE | Refer to 89 Resolves to: VA-262-89 | VA-262-89-Online | 1 |
| 12 | HEX SCREW M5X30 | 4 | ||
| 13 | FLYWHEEL | V-262-13 | V-262-13-Online | 1 |
| 14 | CRANKSHAFT COVER | V-262-14 | V-262-14-Online | 1 |
| 15 | HEX SCREW M5X20 | V-262-15 | V-262-15-Online | 4 |
| 16 | IGNITION COIL | V-262-16 | V-262-16-Online | 1 |
| 17 | STOP SWITCH WIRE | V-262-17 | V-262-17-Online | 1 |
| 18 | NEEDLE BEARING CRANKSHAFT | V-262-18 | V-262-18-Online | 1 |
| 19 | SNAP RING GUDGEON PIN | V-262-19 | V-262-19-Online | 2 |
| 20 | GUDGEON PIN | V-262-20 | V-262-20-Online | 1 |
| 21 | PISTON | V-262-21 | V-262-21-Online | 1 |
| 22 | PISTON RING | V-262-22 | V-262-22-Online | 2 |
| 23 | CYLINDER GASKET | Refer to 90 Resolves to: VA-262-90 | VA-262-90-Online | 1 |
| 24 | CYLINDER ZH1E34F-5B | V-262-24 | V-262-24-Online | 1 |
| 25 | HEX SCREWM5X25 | V-262-25 | V-262-25-Online | 4 |
| 26 | SPARK PLUG BM6A | P-260-55 | P-260-55-Online | 1 |
| 27 | BAFFLE PLATE | V-262-27 | V-262-27-Online | 1 |
| 28 | AIR INLET GASKET | Refer to 90 Resolves to: VA-262-90 | VA-262-90-Online | 2 |
| 29 | AIR INLET PIPE | V-262-29 | V-262-29-Online | 1 |
| 30 | CARBURETOR GASKET | Refer to 90 Resolves to: VA-262-90 | VA-262-90-Online | 1 |
| 31 | CARBURETOR | V-262-31 | V-262-31-Online | 1 |
| 32 | HEX SCREW M5X55 | V-262-32 | V-262-32-Online | 2 |
| 33 | WASHER 5mm | 4 | ||
| 34 | SPRING WASHER 5mm | 4 | ||
| 35 | AIR FILTER HOUSING ASSEMBLY(36,37,38,39) | VA-262-35 | VA-262-35-Online | 1 |
| 36 | AIR FILTER SCREW | V-262-36 | V-262-36-Online | 1 |
| 37 | COVER, OUTER, AIR FILTER | Refer to 35 Resolves to: VA-262-35 | VA-262-35-Online | 1 |
| 38 | AIR FILTER | P-2022820 | P-2022820-Online | 1 |
| 39 | COVER, INNER, AIR FILTER | Refer to 35 Resolves to: VA-262-35 | VA-262-35-Online | 1 |
| 40 | MUFFLER GASKET | Refer to 90 Resolves to: VA-262-90 | VA-262-90-Online | 1 |
| 41 | EXHAUST | V-262-41 | V-262-41-Online | 1 |
| 42 | HEX SCREW M5X60 | V-262-42 | V-262-42-Online | 2 |
| 43 | FUEL TANK ASSY | V-262-43 | V-262-43-Online | 1 |
| 44 | FUEL HOSE ASSY | P-340-61 | P-340-61-Online | 1 |
| 45 | CAP ASSY, FUEL TANK | P-330-50 | P-330-50-Online | 1 |
| 46 | FUEL TANK | V-262-46 | V-262-46-Online | 1 |
| 47 | FRONT HALF HOUSING | V-262-47 | V-262-47-Online | 1 |
| 88 | PULL START ASSEMBL(2,3) | VA-262-88 | VA-262-88-Online | 1 |
| 89 | CRANK CASE ASSEMBLY(4,5,6,7,8,9,10,11,12) | VA-262-89 | VA-262-89-Online | 1 |
| 90 | GGASKET KIT ASSEMBLY(5,23,28,28,30,40) | VA-262-90 | VA-262-90-Online | 1 |
| 48 | HANDLE | V-262-48 | V-262-48-Online | 1 |
| 49 | SCREW M5X25 | V-262-49 | V-262-49-Online | 2 |
| 50 | WASHER 8mm | V-262-50 | V-262-50-Online | 1 |
| 51 | WASHER INSIDE IMPELLER | V-262-51 | V-262-51-Online | 1 |
| 52 | IMPELLER | V-262-52 | V-262-52-Online | 1 |
| 53 | WASHER OUTSIDE IMPELLER | V-262-53 | V-262-53-Online | 1 |
| 55 | NUT M8 | 1 | ||
| 56 | HOUSING IMPELLER | V-262-56 | V-262-56-Online | 1 |
| 57 | SCREW ST4.8 | 11 | ||
| 58 | STOP SWITCH WIRE A | V-262-58 | V-262-58-Online | 2 |
| 59 | SWITCH ON/OFF | V-262-59 | V-262-59-Online | 1 |
| 60 | SCREW M5X30 | 1 | ||
| 61 | THROTTLE LOCK | V-262-61 | V-262-61-Online | 1 |
| 62 | WASHER M6 | 1 | ||
| 63 | NUT M6 | 1 | ||
| 64 | THROTTLE CABLE | V-262-64 | V-262-64-Online | 1 |
| 65 | THROTTLE TRIGGER | V-262-65 | V-262-65-Online | 1 |
| 66 | HOUSING ENGINE | V-262-66 | V-262-66-Online | 1 |
| 67 | BLOWER TUBE UPPER | V-262-67 | V-262-67-Online | 1 |
| 68 | BLOWER TUBE LOWER | V-262-68 | V-262-68-Online | 1 |
| 69 | SCREW M5X10 | 2 | ||
| 70 | FAN COVER ASSY.(72,73,74,75,76,77) | VA-262-70 | VA-262-70-Online | 1 |
| 71 | TIGHTENING SCREW | V-262-71 | V-262-71-Online | 1 |
| 72 | O RING | Refer to 70 Resolves to: VA-262-70 | VA-262-70-Online | 1 |
| 73 | FAN COVER | Refer to 70 Resolves to: VA-262-70 | VA-262-70-Online | 1 |
| 74 | FLAT GASKET 5.5X15X1 | Refer to 70 Resolves to: VA-262-70 | VA-262-70-Online | 1 |
| 75 | SPRING | Refer to 70 Resolves to: VA-262-70 | VA-262-70-Online | 1 |
| 76 | SPRING SCREW | Refer to 70 Resolves to: VA-262-70 | VA-262-70-Online | 1 |
| 77 | SCREW ST4.8X12 | Refer to 70 Resolves to: VA-262-70 | VA-262-70-Online | 1 |
| 78 | SAFETY SWITCH ASSEMBLY(79,80,81,82) | VA-262-78 | VA-262-78-Online | 1 |
| 79 | SCREW ST4.8*16-H-F | Refer to 78 Resolves to: VA-262-78 | VA-262-78-Online | 2 |
| 80 | SWITCH HOUSING 1 | Refer to 78 Resolves to: VA-262-78 | VA-262-78-Online | 1 |
| 81 | STOP SWITCH WIRE A | Refer to 78 Resolves to: VA-262-78 | VA-262-78-Online | 2 |
| 82 | SWITCH FEELER | Refer to 78 Resolves to: VA-262-78 | VA-262-78-Online | 1 |
| 88 | PULL START ASSEMBL(2,3) | VA-262-88 | VA-262-88-Online | 1 |
| 89 | CRANK CASE ASSEMBLY(4,5,6,7,8,9,10,11,12) | VA-262-89 | VA-262-89-Online | 1 |
| 90 | GGASKET KIT ASSEMBLY(5,23,28,28,30,40) | VA-262-90 | VA-262-90-Online | 1 |
