Husqvarna 142 IPL
Husqvarna illustrated parts list prepared for Cutsmart IPL lookup. Use the diagram reference number, part number, or linked Cutsmart SKU to identify the correct spare part.
CHAIN SAWS
| Ref | Description | Part Number | Cutsmart SKU | Qty |
|---|---|---|---|---|
| 1 | JET | 530029813 | 530029813-Online | 1 |
| 2 | SEALING | 530019203 | 530019203-Online | 1 |
| 3 | PIPE | 530029814 | 530029814-Online | 1 |
| 4 | HOSE | 530053435 | 530053435-Online | 1 |
| 5 | SCREW | 530015814 | 530015814-Online | 1 |
| 6 | ADAPTER | 530037465 | 530037465-Online | 1 |
| 7 | GASKET | 530019172 | 530019172-Online | 1 |
| 8 | CARBURETTOR | 530071987 | 530071987-Online | 1 |
| 9 | PASSAGE | 530035587 | 530035587-Online | 1 |
| 10 | SUPPORT | 530047767 | 530047767-Online | 1 |
| 11 | SCREW | 530015896 | 530015896-Online | 1 |
| 12 | HOLDER | 530036582 | 530036582-Online | 1 |
| 13 | SCREW | 530015968 | 530015968-Online | 1 |
| 14 | NUT | 530016008 | 530016008-Online | 1 |
| 15 | AIR FILTER COVER | 545057801 | 545057801-Online | 1 |
| 16 | SCREW | 530015899 | 530015899-Online | 1 |
| 17 | BOLT | 530016044 | 530016044-Online | 1 |
| 18 | MUFFLER | 530069415 | 530069415-Online | 1 |
| 19 | MUFFLER | 530037254 | 530037254-Online | 1 |
| 20 | SCREEN | 530029810 | 530029810-Online | 1 |
| 21 | FLAME PROTECTION | 530037246 | 530037246-Online | 1 |
| 22 | MUFFLER | 530037251 | 530037251-Online | 1 |
| 23 | GASKET | 530019205 | 530019205-Online | 1 |
| 24 | PLATE | 530037640 | 530037640-Online | 1 |
| 25 | SCREW | 530015902 | 530015902-Online | 1 |
| 26 | BEARING | 530056363 | 530056363-Online | 1 |
| 27 | CRANKSHAFT | 530029794 | 530029794-Online | 1 |
CHAIN SAWS
| Ref | Description | Part Number | Cutsmart SKU | Qty |
|---|---|---|---|---|
| 1 | REPAIR KIT | 530035269 | 530035269-Online | 1 |
CHAIN SAWS
| Ref | Description | Part Number | Cutsmart SKU | Qty |
|---|---|---|---|---|
| 1 | STARTER DEVICE | 530071968 | 530071968-Online | 1 |
| 2 | STARTER PULLEY | 530071966 | 530071966-Online | 1 |
| 3 | HANDLE | 530150318 | 530150318-Online | 1 |
| 4 | STARTER ROPE | 530069232 | 530069232-Online | 1 |
| 5 | SCREW | 530021179 | 530021179-Online | 1 |
| 6 | SLEEVE | 530059677 | 530059677-Online | 1 |
| 7 | SPRING | 530021180 | 530021180-Online | 1 |
| 8 | SCREW | 530016080 | 530016080-Online | 1 |
| 9 | SPRING | 530042095 | 530042095-Online | 1 |
| 10 | BAFFLE | 530059959 | 530059959-Online | 1 |
| 11 | STARTER | 530059958 | 530059958-Online | 1 |
| 12 | SCREW | 530015893 | 530015893-Online | 1 |
| 13 | SCREW | 530015892 | 530015892-Online | 1 |
| 14 | IGNITION MODULE | 530071967 | 530071967-Online | 1 |
| 15 | CABLE | 530403257 | 530403257-Online | 1 |
| 16 | SCREW | 530015896 | 530015896-Online | 1 |
| 17 | STOP SWITCH | 503717901 | 503717901-Online | 1 |
| 18 | FLYWHEEL ASSY | 530059637 | 530059637-Online | 1 |
| 19 | WASHER | 530015127 | 530015127-Online | 1 |
| 20 | NUT | 530016134 | 530016134-Online | 1 |
| 21 | SCREW | 545003902 | 545003902-Online | 1 |
| 22 | IGNITION MODULE | 530039239 | 530039239-Online | 1 |
| 23 | THROTTLE ROD | 530029869 | 530029869-Online | 1 |
| 24 | HUB CAP | 530029863 | 530029863-Online | 1 |
| 25 | SCREW | 530029860 | 530029860-Online | 1 |
| 26 | SPRING | 530029861 | 530029861-Online | 1 |
| 27 | THROTTLE TRIGGER | 530069587 | 530069587-Online | 1 |
| 28 | HOSE | 530069247 | 530069247-Online | 1 |
| 29 | FILTER | 530014497 | 530014497-Online | 1 |
| 30 | SCREW | 530016439 | 530016439-Online | 1 |
| 31 | FELLING DOG | 530014381 | 530014381-Online | 1 |
| 32 | SCREW | 530015940 | 530015940-Online | 1 |
| 33 | INSULATOR | 530029870 | 530029870-Online | 1 |
| 34 | TANK | 530052446 | 530052446-Online | 1 |
| 35 | SCREW | 530015843 | 530015843-Online | 1 |
| 36 | HANDLE | 530059961 | 530059961-Online | 1 |
| 37 | MOVEMENT LIMITER | 530052439 | 530052439-Online | 1 |
| 38 | LIMITER | 530029984 | 530029984-Online | 1 |
| 39 | CHECK VALVE | 530026119 | 530026119-Online | 1 |
| 40 | PLUG | 530038264 | 530038264-Online | 1 |
| 41 | FUEL CAP | 530071266 | 530071266-Online | 1 |
CHAIN SAWS
| Ref | Description | Part Number | Cutsmart SKU | Qty |
|---|---|---|---|---|
| 1 | SCREW | 530016154 | 530016154-Online | 1 |
| 2 | CYLINDER COVER | 530059960 | 530059960-Online | 1 |
| 3 | SPARK PLUG | 952030150 | 952030150-Online | 1 |
| 4 | CYLINDER | 530069941 | 530069941-Online | 1 |
| 5 | PISTON | 530069454 | 530069454-Online | 1 |
| 6 | PISTON RING | 530029982 | 530029982-Online | 1 |
| 7 | LOCKING RING | 530015697 | 530015697-Online | 1 |
| 8 | CRANKCASE | 530049794 | 530049794-Online | 1 |
| 9 | SCREW | 530015897 | 530015897-Online | 1 |
CHAIN SAWS
| Ref | Description | Part Number | Cutsmart SKU | Qty |
|---|---|---|---|---|
| 1 | SCREW | 530029879 | 530029879-Online | 1 |
| 2 | LEVER | 530071348 | 530071348-Online | 1 |
| 3 | SCREW | 530015915 | 530015915-Online | 1 |
| 4 | KNEE LINK | 530054741 | 530054741-Online | 1 |
| 5 | SPRING | 530016237 | 530016237-Online | 1 |
| 6 | SCREW | 530016384 | 530016384-Online | 1 |
| 7 | SHAFT PIVOT | 530056531 | 530056531-Online | 1 |
| 8 | SHAFT PIVOT | 530029881 | 530029881-Online | 1 |
| 9 | E-CLIP | 530024419 | 530024419-Online | 1 |
| 10 | SCREW | 530015911 | 530015911-Online | 1 |
| 11 | PEN | 530015913 | 530015913-Online | 1 |
| 12 | SPRING | 530029878 | 530029878-Online | 1 |
| 13 | SPRING | 530015910 | 530015910-Online | 1 |
| 14 | BRAKE BAND | 530052232 | 530052232-Online | 1 |
| 15 | BRAKE BAND | 530052232 | 530052232-Online | 1 |
| 530054802 | CHAIN BRAKE ASSY | 530054802 | 530054802-Online | 1 |
| 16 | COVER | 530053035 | 530053035-Online | 1 |
| 17 | SCREW | 530015911 | 530015911-Online | 1 |
| 18 | SCREW | 530016110 | 530016110-Online | 1 |
| 19 | RETAINER | 530038593 | 530038593-Online | 1 |
| 20 | PEN | 530015826 | 530015826-Online | 1 |
| 21 | PEN | 530015826 | 530015826-Online | 1 |
| 530049483 | CLUTCH COVER | 530049483 | 530049483-Online | 1 |
| 530031135 | WRENCH | 530031135 | 530031135-Online | 1 |
| 530047839 | DECAL | 530047839 | 530047839-Online | 1 |
| 545003026 | LABEL | 545003026 | 545003026-Online | 1 |
CHAIN SAWS
| Ref | Description | Part Number | Cutsmart SKU | Qty |
|---|---|---|---|---|
| 1 | CLUTCH | 530014949 | 530014949-Online | 1 |
| 2 | WASHER | 530015611 | 530015611-Online | 1 |
| 3 | CLUTCH DRUM ASSY | 530047061 | 530047061-Online | 1 |
| 3 | CLUTCH DRUM | 530048132 | 530048132-Online | 1 |
| 4 | WASHER | 530015907 | 530015907-Online | 1 |
| 5 | OIL PICK-UP | 530014776 | 530014776-Online | 1 |
| 6 | SCREEN | 530056533 | 530056533-Online | 1 |
| 7 | SEALING | 545037101 | 545037101-Online | 1 |
| 8 | SCREW | 530015896 | 530015896-Online | 1 |
| 9 | OIL PUMP | 530014410 | 530014410-Online | 1 |
| 10 | PUMP | 530029833 | 530029833-Online | 1 |
| 11 | HOSE | 545033501 | 545033501-Online | 1 |
| 12 | SCREW | 530015896 | 530015896-Online | 1 |
| 13 | NUT | 530015917 | 530015917-Online | 1 |
| 14 | PLATE | 530047855 | 530047855-Online | 1 |
| 15 | SEALING | 530019228 | 530019228-Online | 1 |
| 16 | SUPPORT | 530036043 | 530036043-Online | 1 |
| 17 | BOLT | 530015877 | 530015877-Online | 1 |
| 18 | SCREW | 530015878 | 530015878-Online | 1 |
| 19 | CHAIN CATCHER | 530029850 | 530029850-Online | 1 |
| 20 | SCREW | 530015893 | 530015893-Online | 1 |
| 21 | COVER | 530052428 | 530052428-Online | 1 |
| 22 | NUT | 530015922 | 530015922-Online | 1 |
| 23 | GUIDE | 530029830 | 530029830-Online | 1 |
| 24 | CHOKE CONTROL | 530029831 | 530029831-Online | 1 |
| 25 | CRANKCASE | 530071991 | 530071991-Online | 1 |
| 26 | NUT | 530015922 | 530015922-Online | 1 |
| 27 | SCREW | 530016037 | 530016037-Online | 1 |
| 28 | TANK CAP ASSY | 501765602 | 501765602-Online | 1 |
