Lawn Star LSMP 3257 ME Mower IPL
This IPL page has been prepared from the Lawn Star 2026 spare parts manual. Use the diagram reference numbers together with the parts table below.
Spare parts list
| Ref | Description | Part Number | Cutsmart SKU | Qty |
|---|---|---|---|---|
| 1 | Handle upper, Insulated | M-215-10 | M-215-10-Online | 1 |
| 49 | Base, Lawnmower | M-302-00 | M-302-00-Online | 1 |
| 2 | Lawnmower switch, 16A | MA-501-16 | MA-501-16-Online | 1 |
| 50 | Washer 17x8x1.0 | M-125-00 | M-125-00-Online | 4 |
| 3 | Nylon washer | M-329-00 | M-329-00-Online | 4 |
| 51 | M8 x 16 Motor Bolts | M-123-16 | M-123-16-Online | 4 |
| 4 | Screw, HiLo,Pan Posi # 2, 4.8 x 22mm | T-150-00 | T-150-00-Online | 6 |
| 52 | Key, electric motor | M-130-00 | M-130-00-Online | 1 |
| 7 | Screw, Self-Tapper, Pan Posi # 2, 3.5 x 16mm | T-151-00 | T-151-00-Online | 2 |
| 53 | Coupling / Fan 20mm, Black, Electric Motor | M-310-00 | M-310-00-Online | 1 |
| 11 | Cable Tie T30R | M-405-00 | M-405-00-Online | 2 |
| 54 | Friction Washer, Coupling Fan | M-311-00 | M-311-00-Online | 1 |
| 12 | Handle, lower | M-211-53 | M-211-53-Online | 1 |
| 55 | Disc, blade | M-252-00 | M-252-00-Online | 1 |
| 13 | Coach bolt, M8X46 | M-120-00 | M-120-00-Online | 2 |
| 56 | Friction Washer bolt | M-312-00 | M-312-00-Online | 1 |
| 14 | Washer 17x8x1.0 | M-125-00 | M-125-00-Online | 18 |
| 57 | Insulated Bolt, Quadrablade Disc, Electric | M-313-00 | M-313-00-Online | 1 |
| 15 | Knob, handle complete with nut | M-326-00 | M-326-00-Online | 2 |
| 60 | Bracket, height adjuster | M-221-53 | M-221-53-Online | 1 |
| 16 | Rod, flap | M-116-53 | M-116-53-Online | 1 |
| 61 | Cup head screw M6X16 | M-110-20 | M-110-20-Online | 9 |
| 17 | Spring, flap | M-210-53 | M-210-53-Online | 1 |
| 62 | Bearing 6001-2RS | M-150-53 | M-150-53-Online | 8 |
| 18 | Split-pin | M-115-53 | M-115-53-Online | 4 |
| 63 | Height adjuster Lever (63,64,65) | M-220-53 | M-220-53-Online | 1 |
| 19 | Bolt, Coach M8 lower handle | M-119-00 | M-119-00-Online | 4 |
| 64 | Knob, height adjuster | Refer to 63 Resolves to: M-220-53 | M-220-53-Online | 1 |
| 20 | Washer | M-112-53 | M-112-53-Online | 3 |
| 65 | Height adjuster lever | Refer to 63 Resolves to: M-220-53 | M-220-53-Online | 1 |
| 21 | Nut M8 | M-113-00 | M-113-00-Online | 12 |
| 67 | Bracket, right - lower handle | M-222-53 | M-222-53-Online | 1 |
| 22 | Bolt Hex Flange M8X20 | M-119-53 | M-119-53-Online | 6 |
| 68 | Flap | M-308-53 | M-308-53-Online | 1 |
| 23 | Bracket, left - lower handle | M-223-53 | M-223-53-Online | 1 |
| 69 | Nut M6 | T-111-00 | T-111-00-Online | 6 |
| 25 | Bracket, lower rear axle | M-327-53 | M-327-53-Online | 2 |
| 70 | Bracket, guard | Refer to 71 Resolves to: M-314-00 | M-314-00-Online | 3 |
| 26 | Mulch blade, 53cm(M-255-57) | 80-02557 | 80-02557-Online | 1 |
| 71 | Guard assembly (61; 70; 71) | M-314-00 | M-314-00-Online | 1 |
| 27 | Spring washer M6 | M-132-00 | M-132-00-Online | 4 |
| 72 | Frame, grass catcher | M-209-53 | M-209-53-Online | 1 |
| 28 | Bolt M6X16 | T-110-20 | T-110-20-Online | 4 |
| 73 | Handle, grass catcher | M-306-53 | M-306-53-Online | 1 |
| 29 | Bush, rear axle | M-322-53 | M-322-53-Online | 4 |
| 74 | Grass bag | M-410-53 | M-410-53-Online | 1 |
| 30 | Axle assembly, rear | M-204-53 | M-204-53-Online | 1 |
| 75 | Cover, grass bag | M-307-53 | M-307-53-Online | 1 |
| 31 | Wheel 9", rear with dual ball bearings and hubcap (31,59, 62) | M-370-53 | M-370-53-Online | 2 |
| 76 | Bolt, M8x70 square shank | M-111-70 | M-111-70-Online | 1 |
| 32 | Nyloc Nut M10 | M-105-00 | M-105-00-Online | 4 |
| 77 | Bolt, M8x40 square shank | M-111-40 | M-111-40-Online | 1 |
| 33 | Washer M10 | M-128-53 | M-128-53-Online | 4 |
| 78 | Mulch plug, 21 inch | M-350-53 | M-350-53-Online | 1 |
| 34 | Bush nylon | M-329-10 | M-329-10-Online | 2 |
| 35 | Height adjuster bar | M-206-53 | M-206-53-Online | 1 |
| 80 | Washer, swing blade bolt | M-104-00 | M-104-00-Online | 4 |
| 36 | Spring, counterbalance | M-207-53 | M-207-53-Online | 1 |
| 81 | Spring Washer, swing blade bolt | M-103-00 | M-103-00-Online | 4 |
| 37 | Axle assembly, front (updated to 86) | M-203-53 | M-203-53-Online | 1 |
| 82 | Swing blade(M-254-57) | 80-02574 | 80-02574-Online | 4 |
| 38 | Wheel 8", front with dual ball bearings and hubcap (31,58, ) | M-360-53 | M-360-53-Online | 2 |
| 83 | Bolt, swing blade M10x20 | M-102-00 | M-102-00-Online | 4 |
| 39 | Bush, front axle (updated to 87) | M-320-53 | M-320-53-Online | 2 |
| 85 | Capacitor 40uF | M-621-40 | M-621-40-Online | 1 |
| 40 | Bracket, front axle LHS (updated to 86) | M-201-57 | M-201-57-Online | 1 |
| 86 | Axle assembly, front(Upgraded part) | M-203-57 | M-203-57-Online | 1 |
| 41 | Mower deck 53 cm - colour red RAL 3001- bag | M-200-53 | M-200-53-Online | 1 |
| 87 | Bush front axle (Upgraded part) | M-320-48 | M-320-48-Online | |
| 43 | Lid, Lawnmower | M-301-00 | M-301-00-Online | 1 |
| 88 | Bracket front axle RHS (updated to 86) | M-202-57 | M-202-57-Online | |
| 44 | Cowl, Lawnmower | M-300-00 | M-300-00-Online | 1 |
| 89 | Fan for motor | M-626-11 | M-626-11-Online | 1 |
| 45 | Motor, 3200 watt | M-626-10 | M-626-10-Online | 1 |
| 46 | Bolt M8 x 45 | M-126-00 | M-126-00-Online | 3 |
| 47 | Washer 25x8x1.5 Base | M-124-00 | M-124-00-Online | 3 |
| 48 | Cable Clamp, Base | M-303-00 | M-303-00-Online | 1 |
